To produce full‑bodied embossed 3‑D prints, using high‑quality adhesive powder and following standardized operating procedures are key to finished‑product success. The 3D hot‑melt adhesive powder from Jiangxi Juge New‑Material is compatible with DTF white‑ink 3‑D printing technology, featuring simple operation and stable forming performance.
Standard Operating Steps:
1.White Ink Amount: W 90%
Printing Process
Pre-plate Temperature: 60°C
Drying Temperature: 80°C
Conveyor Belt Speed: 40% (0.37 m/min)
Powder Vibrating Speed: 60%
2. Lamination and Heat Pressing Process
Heat Pressing Temperature: 120°C
Heat Pressing Time: 8 seconds
3. Drying Process
Drying Temperature: 100°C
Drying Time: 2 minutes
Practical Processing Tips
▪️Higher‑relief effect: Increase white‑ink thickness and apply more adhesive powder.
▪️Stretchy knit fabrics: Select our high‑elasticity 3D powder to prevent print cracking during stretching.
▪️Moisture‑proof storage: Store finished transfer prints in a cool, dry place to stop powder caking caused by moisture absorption.
Jiangxi Juge New‑Material supplies premium 3D hot‑melt adhesive powder directly from factory. Custom‑mesh specifications and free samples are available.
